Description
The Cutter Cum Sifter Machine represents a highly efficient dual-function processing system engineered to perform uniform cutting and simultaneous grading within a single integrated unit. Designed for agro and food products such as supari (betel nut), tobacco, dry fruits, dates, amla, dalia, herbal materials, and similar applications, this machine streamlines production by combining precision blade cutting with an inclined sifting mechanism. The calibrated cutting chamber ensures accurate size control with minimal wastage, while the built-in sifting assembly effectively separates fines and dust to deliver a clean, graded final output. Available in 15″ and 30″ capacity variants, the system reduces manual handling, improves throughput efficiency, and enhances overall product consistency. Built for continuous industrial operation, it offers manufacturers a space-efficient, productivity-driven solution for integrated cutting and grading in medium to high-volume processing environments.
The Cutter Cum Sifter Machine is a robust and efficient processing unit designed for uniform cutting and simultaneous grading of products such as betel nut (supari), dry fruits, dates (khajoor), gooseberry (amla), broken wheat (dalia) herbal materials, and similar agro products. The machine combines cutting and sifting operations into a single compact system, ensuring consistent output with minimal manual handling.
The cutting assembly is equipped with hardened and precision-engineered blades that cut the incoming product uniformly. Cut size control is achieved using a curved perforated sheet which contains precision-drilled holes of the specified diameter, corresponding to the desired cut size. Only material achieving the required size passes through the perforations, while oversized material remains within the cutting chamber for further cutting.
Once the desired cut size is achieved, the product automatically passes through the sifting assembly, where grading is performed through an inclined oscillating sieve operating in a controlled to-and-fro motion driven by a single motor. This process effectively separates fine dust and undersized particles from the usable product. The graded material is then discharged through a dedicated outlet for collection or further processing.
The machine is designed for continuous operation, low maintenance, and consistent performance, making it suitable for medium- to high-capacity production environments.
General Specifications
| Parameter | 15″ Model | 30″ Model |
|---|---|---|
| Cutting Blades | 6 (4 moving + 2 fixed) | 12 (8 moving + 4 fixed) |
| Drive Motor | 5 HP | 10 HP |
| Cutting Size Range | 4 – 16 mm | 4 – 16 mm |
| Output Capacity | 250 – 350 kg/hr | 600 – 800 kg/hr |
| Max Wastage | 4 – 5% | 4 – 5% |
| Sieve Size | As per product specifications | As per product specifications |
| Body Construction | Mild Steel (MS) | Mild Steel (MS) |
| Power Consumption | 3.75 kW | 7.5 kW |
| Electricity Supply | 3 Phase, 440 V | 3 Phase, 440 V |
| Machine Dimensions | 44 x 64 x 68 inches approx. | 50 x 72 x 68 inches approx. |
| Machine Weight | 500 kg approx. | 650 kg approx. |
Optional Add-ons: Infeed Conveyor, Collection Tray + Trolley.
